Heycarbons Wood Pelletized Activated Carbon Manufacturer From China
- Over 20 years experience in wood Pelletized activated carbon manufacturing.
- Annual output 18000 tons
- 16pcs Production Patents.
- High CTC 170%, Clean, Uniform size.
- Popular in the wood pelletized activated carbon market.
Heycarbons Wood Pelletized Extruded Activated Carbon Types
Wood Pelletized Extruded Activated Carbon
This is a high-quality gas phase adsorption wood columnar activated carbon with the characteristics of high strength, high activity, low flow resistance, low density, high working capacity, etc. This product has superior performance in VOCs organic solvent recovery applications, high cost performance, and high adsorption capacity.
Wood Pelletized Activated Carbon Uses Application
- VOCs treatment
- Gas purification
- Oil and gas recovery
- Air purification
Wood Pelletized Activated Carbon Specifications
| Product size | Iodine value | CTC | Specific surface area | Ash | Package |
|---|---|---|---|---|---|
| 2-4mm | 900-1200mg/g | 80-110% | 1200-1600m2/g | ≤7% | 25KG, 400KG |
Wood Pelletized Columnar Activated Carbon Catalyst
This is a high-strength activated carbon catalyst made from high-quality activated carbon through a special process. It is a microporous activated carbon with a high specific surface area. It has a developed pore barrier structure and high catalytic performance.
Wood Pelletized Columnar Catalyst Activated Carbon Uses Application
- Treatment of high-concentration wastewater by catalytic oxidation
- Hydrogen Sulfide H2S Removal
- Air purification
- Catalyst carrier
Wood Pelletized Columnar Catalyst Activated Carbon Specifications
| Product size | CTC | Specific surface area | Average pore size | Total pore volume | Package |
|---|---|---|---|---|---|
| 2-4mm | 60-80% | ≥1000m2/g | ≥2.0nm | ≥0.55cm3/g | 25KG, 450KG |
Physical Method Wood Pelletized Extruded Activated Carbon
This is a pelletized activated carbon made from high-quality bamboo and wood, activated by high-temperature steam. It has the characteristics of high specific surface area, large adsorption capacity, and low ash content.
Wood Pelletized Activated Carbon Uses Application
- VOCs treatment
- Gas purification
- Oil and gas recovery
- Air purification
Wood Pelletized Activated Carbon Specifications
| Product size | Iodine value | CTC | Specific surface area | Ash | pH | Package |
|---|---|---|---|---|---|---|
| 2-4mm | 800-1200mg/g | 70-120% | 1200-1600m2/g | ≤10% | 7-11 | 25KG, 400KG |
Activated Carbon Specific Surface Area of Different Materials
When the CTC is same, activated carbons of different materials have different specific surface areas. Different specific surface areas have different adsorption capacities.
Coconut shell based pellet activated carbon Specific surface area ＞Wood based pellet activated carbonSpecific surface area ＞ Coal based pellet activated carbon Specific surface area
If you want to know more detailed activated carbon specifications, please contact heycarbons.
Wood Pelletized Activated Carbon Uses: Capture Gasoline Vapors in Car
The main function of wood columnar activated carbon in the automotive fuel evaporation control system (EVAP) is to adsorb and store fuel vapor to prevent it from being discharged into the atmosphere.
At the same time, it is released back to the combustion chamber for combustion at the appropriate time, improving fuel economy and reducing environmental pollution.
Wood Activated Carbon Functions
- Adsorption stage: When the vehicle is turned off or idling, fuel vapor enters the carbon canister and the wood activated carbon adsorbs gasoline vapor.
- Regeneration stage: When the vehicle is running, the ECU (engine control unit) will control the valve to open, and air will flow through the carbon canister, bringing the adsorbed gasoline vapor into the intake manifold. After mixing with the air, it enters the combustion chamber for combustion, thereby improving fuel utilization.
There are two types of wood based activated carbon used in cars to capture gasoline vapors:
| Diameter of pellets | CTC | Ash | Hardness | Moisture | Bulk density | |
|---|---|---|---|---|---|---|
| Wood base pellet activated carbon 1 | 2 mm | > 90% | < 7% | > 75% | < 5% | < 0.4g/l |
| Wood base pellet activated carbon 2 | 2 mm | > 100% | < 7% | > 75% | < 5% | < 0.4g/l |
Factors affecting the performance of wood pelletized activated carbon
- Matching of pore size: It needs to match the gasoline vapor molecules. Too large or too small will affect the adsorption efficiency.
- Adsorption capacity: The activated carbon should have sufficient adsorption capacity to ensure the long-term use of the carbon canister.
- Desorption efficiency: The desorption process must be thorough to avoid long-term saturation of the activated carbon, which will affect the subsequent adsorption capacity.
Wood Pelletized Activated Carbon for Solvent Recovery in Adhesive Tape Factories
The tape factory uses a lot of VOCs organic solvents (such as toluene, ethyl acetate, acetone, etc.) during the production process. These solvents will evaporate into the air, causing resource waste and environmental pollution. Wood columnar activated carbon has a high specific surface area and rich microporous structure, which can effectively adsorb these organic solvents and realize solvent recovery and reuse.
The following table shows you the parameter requirements of activated carbon used for solvent recovery in the tape factory and the data of the sample inspection: Customers require CTC80%min
| Test items | CTC | Proportion | Moisture | Ash | Strength | Specific surface area | Particle size |
|---|---|---|---|---|---|---|---|
| Unit | % | g/L | % | % | % | cm2/g | mm |
| Testing standards | ASTM D3467 | ASTM D2854 | ASTM D2867 | ASTM D2866 | ASTM D3802 | – | ASTM D2862 |
| Parameter requirements | ﹥80 | 360-420 | ﹤5 | ≤10 | ≥95 | ≥1250 | 3.8-4.2 |
| 1# | 91.77 | 397.4 | 3.0 | 3.90 | 98.95 | 1455 | 3.99 |
| 2# | 93.58 | 393.2 | 3.4 | 3.54 | 98.19 | 1604 | 4.17 |
| 3# | 83.84 | 419.3 | 3.6 | 6.71 | 98.81 | 1366 | 4.01 |
Circular desorption to improve recycling efficiency
The solvent adsorbed by wood based pelletized activated carbon can be desorbed by heating, steam purging or vacuum analysis to restore the adsorption capacity of the activated carbon, and the desorbed solvent can be condensed and recycled to improve resource utilization.
More information about wood activated carbon:
Heycarbons Wood Pelletized Activated Carbon for Sale
Heycarbons provides a full range of activated solutions at competitive prices.
What Clients Say on Heycarbons Activated Carbon
Custom OEM Heycarbons Wood Pelletized Activated Carbon for Sale
Heycarbons has proudly served the activated carbon industry with high-quality products since 2005, we can customize cylindrical activated carbon for your project.
- Customize different raw materials according to different applications.
- Cost-effective solutions customized according to customer applications. such as impregnated Alkaline or acidic substances, KOH, NAOH, K2CO3, KI, CuO, MgO, KMnO4... Accept OEM
- Customized bag, carbon pellets size, CTC, iodine value, ash, H2S working capacity, etc.
Steps to Custom Heycarbons Wood Pelletized Activated Carbon for Sale
Consultation
By understanding your needs and requirements, our salesmen work with you to submit the appropriate activated carbon solution.
Quotation
Heycarbons expert customer service will provide you with a free quote based on your requirements as well as product specifications and quantities.
Production
Heycarbons has sufficient inventory and strong production capacity, and will report production progress to you from time to time.
Shipping
Heycarbons know you need to receive the product as soon as possible, after rigorous quality checks and protective packaging, by fedex shipping.
Wood Pelletized Activated Carbon FAQs
Heycarbons provides on demand activated carbon solutions worldwide, product quality and customer service are highly rated by our partners and customers.
- Testing of selected raw materials
- Comprehensive display and monitoring of production temperature and time
- Sampling inspection of finished products
- Support any form of third-party testing , such as SGS
1. T/T Deposiit + Balance against copy of B/L
2. L/C
3. T/T deposit + L/C for balance
1. If necessary, the technician can go to the site to guide .
2. Order goods are consistent with the sample and TDS
3. Any quality problems occur, the seller will provide solutions within 24 hours.
4. If the package is damaged due to the seller’s negligence, resulting in a shortage of goods,
the seller should make compensation based on mutual agreement.
For customers’ trial orders, we actually do not have a specific MOQ, any amount is acceptable.
Heycarb have to choose a cost-effective transportation method and quantity based on your specific situation.
Normally , 5-7days , also depend on quantity
Yes, Heycarb provide samples for free.
Normally 25kgs/bag , 20kgs/bag , 500kgs/bag , black bag
Support any OEM drawing design bag .
